Description
Features
- Outdoor Wall Mount(Dual -Technology Sensor)
- Pet immunity
- Passive infrared and microwave combination detection technology
- Selectable pulse counting (2/4) function
- Microwave detection range adjustable
- Selectable single-infrared detection function
- Green, Red, Yellow LED indicator
- Microprocessor chip design
- Alarm output N.O/N.C selectable
- Ingress protection of IP 65, all-round rubber seal ring, effectively protecting against rain, mist and incest.
Specifications:
| Pattern Coverage – Wide | (15.24m x 12.19m) 50′ x 40′ |
| Pattern Coverage – Long Range | (2.13m x 19.8m) 7′ x 65′ |
| Selectable Pulse Count | 2/4 |
| Selectable PIR Sensitivity | 60% ~ 120% |
| LED Display | PIR, Microwave, Alarm |
| Operating Temperature | -20° C ~ +50° C (-4° F ~ +122° F) |
| Power Supply | 10.5 – 16VDC |
| Current Consumption | 35 mA max |
